Overview
EN10216 1.4462 Seamless Pipe is a steel pipe made from a whole round steel perforated without welded seams on the surface. It is usually produced by hot rolling, cold rolling, cold drawing and extrusion. The outer and inner walls are smooth and burr-free. The EN10216 1.4462 Seamless Pipe can be used for the manufacture of various machine parts and pipe fittings since it has excellent qualities.
EN10216 1.4462 Seamless Pipe is resistant to high temperatures, impact corrosion and ammonia corrosion. It is also resistant to scaling, staining and corrosion. It has a long service life, reduces maintenance time and saves money. It can effectively reduce the waste of resources caused by maintenance, and is manufactured with good workmanship, allowing for direct replacement of fittings.
Detailed Info.
01. EN10216-5TC1/TC2 W. Nr. 1.4462 Seamless Stainless Steel Tubes for Pressure Purposes
02. Process method: cold finished
03. Surface finish: CFD, CFA.
04. Material: W. Nr. 1.4462, X2CrNiMoN22-5-3
05. Specification: EN10216-5TC1, EN10216-5TC2, EN ISO 8492, EN ISO 3651-2, EN ISO 10893-1, EN ISO 10893-10.
06. Size
a) O.D.: 12 to 139.7 mm.
b) W.T.: 1.0 to 10.0 mm.
07. Length: Max. 25 meters.
08. Tolerance: D3/T3, D3/T4, D4/T3, D4/T4
09. Certificate: EN10204-3.1, EN10204-3.2
10. Applications: Oil & gas, marine, pressure vessel.
11. Packing: end caps, plywood case, wooden case, iron case.
12. Certificate: TS, ISO 9001, PED 97/23/EC, ASME, ABS, DNV-GL
Some of the quality tests carried out by us include:
Corrosion Test | Conducted only when specially requested by the client |
Chemical Analysis | Test is done as per required quality standards |
Destructive/ Mechanical Test | Tensile | Hardness | Flattening | Flaring |
Eddy Current Test | To detect homogeneities by using Digital Flaw-mark Testing System |
Hydrostatic Test | 100% Hydrostatic Testing carried out for checking tube leakage, and biggest pressure we can support 20Mpa/5s. |
Air Under Pressure Test | To check any evidence of air leakage |
Visual Inspection | Every single length of tube is subjected to visual inspection by trained staff for detecting surface flaws & other imperfections |
