TP316Ti stainless steel pipe/tube, TP316Ti Seamless austenitic stainless steel pipe/tube, TP316Ti Seamless stainless steel pipe/tube, TP316Ti seamless tubes, 1.4571 stainless steel tube, 1.4571 stainless seamless tube, seamless 1.4571 pipe, 1.4571 stainless steel bended tube.
Huzhou Gaolin Stainless Steel Tube Manufacture Co., Ltd. is a professional manufacturer of 316Ti / 1.4571 / TP316Ti / S31635 Seamless Stainless Steel Pipe / Tube.
Product Name: 316Ti / 1.4571 / TP316Ti / S31635 Seamless Stainless Steel Pipe / Tube
Features:
1) Keywords: Seamless super austenitic stainless steel pipe/tube, Bright Annealing stainless steel pipe/tube, stainless steel pipe, stainless steel tube, 06Cr17Ni12Mo2Ti, TP316Ti, 1.4571, 316Ti, S31635, X6CrNiMoTi17-12-2 (EN/ISO/DIN)
2) Process method: Cold drawn/cold rolled
3) Surface finish: Annealing/pickling/manual polishing/ mechanical polishing
4) Material: 06Cr17Ni12Mo2Ti (GB), TP316Ti, 1.4571, 316Ti, S31635, X6CrNiMoTi17-12-2 (EN/ISO/DIN), 08X17H13M3T (GOST)
Chemical Composition (%)
Carbon 0.08
Manganese 2.00
Phosphorus 0.045
Sulfur 0.030
Silicon 0.75
Chromium 16.0–18.0
Nickel 10.0–14.0
Molybdenum 2.0–3.0
Nitrogen 0.10
Niobium
Titanium 5×(C+N)-0.70
Other
Elements
Cu 1.00–2.00
Mechanical Properties
Solution treatment with 1040℃ temperature
Tensile Strength 515 MPa
Yield Strength 205 MPa
Elongation 35%
Rockwell 90 HRB
5) Standards: GB/T 14975, GB/T 14976, GB 13296, ASTM(ASME) (SA)A312/213/269/M, GOST 9941-81, DIN17456/17458, EN10216-5, JIS G3448/3459/3463
6) Size:
A) NPS: 1/8" to 12"
B) Schedule: 5/5S, 10/10S, 20/20S, 40/40S, 80/80S
Acc. To ASME/ANSI B36.19M or ASME B36.10M
C) O. D.: 6mm to 323.9mm
D) W. T.: 0.5mm to 15mm
7) Length: Max. 20 meters
8) Delivery conditions: (bright) Annealed, Pickled and Polished
9) Inspection: ISO 9001-2015, PED 2014-68-EU, ASME, DNV, ABS
10) Applications: Processing plant for sulphuric, phosphoric and acetic acids fluid and gas transportation; Structure and Machining; Pulp and paper processing; Components in gas scrubbing plants; Seawater cooling equipment; Oil refinery components;
11) Packing: Seaworthy wooden cases/plywood box/steel framed cases/ simple packaging
Titanium is used as a stabilizing element in austenitic stainless steels with higher carbon contents, and will reduce the formation of chromium carbides. It can improve the aqueous corrosion resistance of welds made in higher carbon grades. Actually, 316Ti is a derivative of 316 in the same way that 321 is related to 304. In fact, 321 is the titanium stabilized version of 304, but while 321 is common in the petrochemical and aerospace industries, 316Ti is not.
The reason for the popularity of 316Ti in Europe is really an historical one. 316Ti exists as the preferred material in many specifications that have not been changed in years – it is basically Germany and the Eastern European countries that keep the grade alive. Regions to the west, south and north of Germany have since long changed to mainly using 316/316L for chemical process and aqueous corrosion applications.
Although it can have a higher carbon content, there seems to be no mechanical property advantage to 316Ti since there is no difference in minimum yield stress for the three variations 316/1.4401, 316L/1.4404, 316Ti/1.4571 in any of the basic EN standards, EN 10088-2 (General application), EN 10088-4 (Structural application) and 10028-7 (Pressure vessel application). In all three Euronorms, the Rp0.2 (YS) is listed as minimum 220 MPa (32 KSI) for plate. In ASTM standards there is a slightly lower YS for 316L (25 KSI) versus 316 and 316Ti (30 KSI), but since nearly all 316L is dual certified as 316, there is no practical difference. The ASME Section VIII Design Allowable Values (DAV) for 316, 316H and 316Ti are the same all the way through the maximum permitted temperature of 1500° F. Note that this is due, in part, to the requirement that any austenitic stainless used at 1000° F or higher must have 0.04% minimum carbon.
